Hyundai Automatic 3-Mode Pump Pressure Controller Unit

RM 160.00

Hyundai Automatic 3-Mode Pump Pressure Controller Unit..
Model HY-15

This digital controller starts and stops pump through MCU according to water flow and pressure.
Completely replace the traditional pump control systems, which composed of pressure tank, pressure switch, water shortage protection set, check valve etc. Compared with traditional electronic [pressure control, the controller has the following obvious features and advantages.

**3-Modes**
.Pressure mode - Pump motor through MCU receive pressure data and flow signal to control pump start and stop and implement relative protection and failure display function.

.Timer mode - Pump motor through MCU receive flow signal to control pump start and stop. Start again according ti set time and implement relative protection and failure display function.

.Flow mode - Pump motor through MCU receive flow signal to control pump start and stop and implement relative protection and failure display function.

**Specifications**
Brand Hyundai
Model HY-15
Rated voltage 220 - 240V 50/60Hz
Max power 1.1kW
Max current 10A
Max pressure 10Bar
Max ambient temperature 50°C
Timer setting 0.5H / 6H / 24H
Pressure adjustable range 1.2 - 2.5Bar
Default pressure setting 1.5Bar
Protection degree IP65
Inlet/outlet 25mm BSP male (standard 1")
Pre-wire with a standard 3 pin plug
Dimension L146 x W151 x H186mm
Net weight 1.08kg
Gross weight 1.29kg
Warranty 12 months

PRICE RM160.00..(Hyundai Corporation Korea)..
